Basic Information
Place of Origin: | Qingdao, China |
Brand Name: | TSKY |
Certification: | SGS, ISO, BV, CE |
Model Number: | BP750S |
Minimum Order Quantity: | 1 set |
Price: | Negotiation |
Packaging Details: | Export standard container: 20GP or 40GP, 40HC |
Delivery Time: | 7-15 working days after confirmed order |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 10 sets per month |
Detail Information:
Name: | BP750S Skip Hoist Feeding Precast Concrete Batching Plant | Theoretical Productivity: | 15m³/h |
Mixer Model: | MP750 | Mixing Motor Power: | 30Kw |
Feeding Mode: | Skip Hoist Feeding Mode | Cycling Period: | 180s |
Max. Aggregate Size: | 40mm | Aggregate Bin Capacity: | 3*6m³ |
Aggregate Weighing Precision: | ±2% | Cement Weighing Precision: | ±1% |
Fly Ash Weighing Precision: | ±1% | Water Weighing Precision: | ±1% |
Additive Weighing Precision: | ±1% | Bolted Cement Silo: | As Per Customer's Demand |
Power Voltage/Frequency: | AC380V / 50HZ | Warranty: | 12 Months |
Discharge Height: | 3.8m/4.2m | ||
High Light: | 15m³ Concrete Batching Plant, 30KW Concrete Batching Plant, 15m³ Precast Batch Plant | ||
Product Description:
BP750S Skip Hoist Feeding Precast Concrete Batching Plant
Precast Concrete Batching Plant can be credited for supplying the utmost critical segments utilized for world-wide infrastructure to include buildings, bridges, parking decks, road surfaces, retaining walls.
Features Of BP750S Skip Hoist Feeding Precast Concrete Batching Plant
The BP750S skip hoist feeding precast concrete batching plant is specially designed for production line of middle & small scale precast manufacture, which has the advantage of small space occupied and less investment.
The BP750S skip hoist feeding precast concrete batching plant has compact structure with skip hoist feeding system, which is easy to disassemble and transport, which can maximize the savings for customers up-front input costs and maintenance costs.
The BP750S skip hoist feeding precast concrete batching plant is equipped with the planetary concrete mixer, which can get the homogenous mixing result in the shortest time.
The control system of the BP750S skip hoist feeding precast concrete batching plant can be customerised with manual operation, semi-auto operation and automatic operation.
Technical Parameter List of the BP750S skip hoist feeding precast concrete batching plant
Model | BP500S | BP750S | BP1000S | BP1500S | BP2000S |
Theoretical Productivity | 10m³/h | 15m³/h | 20m³/h | 30m³/h | 40m³/h |
Mixer Model | MP500 | MP750 | MP1000 | MP1500 | MP2000 |
Mixing Motor Power | 18.5Kw | 30Kw | 37Kw | 55Kw | 2*37Kw |
Feeding Mode | Skip Hoist Feeding Mode | ||||
Cycling Period | 180s | 180s | 180s | 180s | 180s |
Max. Grain Size | 40mm | 40mm | 40mm | 40mm | 50mm |
Aggregate Bin Capacity | 3*6m³ | 3*6m³ | 3*12m³ | 3*12m³ | 4*20m³ |
Aggregate Weighing Precision | ±2% | ±2% | ±2% | ±2% | ±2% |
Cement Weighing Precision | ±1% | ±1% | ±1% | ±1% | ±1% |
Fly Ash Weighing Precision | ±1% | ±1% | ±1% | ±1% | ±1% |
Water Weighing Precision | ±1% | ±1% | ±1% | ±1% | ±1% |
Additive Weighing Precision | ±1% | ±1% | ±1% | ±1% | ±1% |
