ST/S800 Steel Cord 800mm Fire Resistant Conveyor Belt


Basic Information

Place of Origin:

Qingdao, China

Brand Name:

TSKY

Certification:

SGS, ISO, BV, CE

Model Number:

ST/S800

Minimum Order Quantity:

100m

Price:

Negotiation

Packaging Details:

Export standard container: 20GP or 40GP, 40HC

Delivery Time:

7-15 working days after confirmed order

Payment Terms:

L/C, T/T, Western Union

Supply Ability:

10000m per day

Detail Information:

Name:

ST/S800 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

Max. Diameter Of Steel Cord:

3.5mm

Top Rubber Cover Thickness:

5.0mm

Bottom Rubber Cover Thickness:

5.0mm

Belt Width:

800mm-1800mm

No. Of Steel Cord:

75-171

Warranty:

12 Months



High Light:

ST/S800 Fire Resistant Conveyor Belt

800mm Fire Resistant Conveyor Belt

ST/S800 Steel Cord Conveyor Belt

Product Description:

ST/S800 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

 Features of ST/S800 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

 The ST/S800 fire resistant steel cord conveyor belt is also called ST/S800 fire retardant steel cord conveyor belt.

 The ST/S800 fire resistant steel cord conveyor belt fire retardant conveyor belt uses galvanize steel cord with high strength and low elongation. The top rubber cover and bottom rubber cover are made of high quality rubber material with fire resistant (fire retardant) & anti-static.

 Under constant tension, the ST/S800 fire resistant steel cord conveyor belt fire retardant conveyor belt can be used to transport materials in the fire resistant (fire-retardant) and static electricity-conducting environment of coal mines by pasting and vulcanizing.

 TheST/S800 fire resistant steel cord conveyor belt fire retardant conveyor belt is suitable for use in underground mines.

 The ST/S800 fire resistant steel cord conveyor belt fire retardant conveyor belt is fire-resistant (fire-retardant), anti-static, high tensile strength, long service life, good trough formation and good flexibility resistance.

 Therefore, the ST/S800 fire resistant steel cord conveyor belt fire retardant conveyor belt is suitable for long-distance, large-span, large conveying capacity and high speed transportation project.

 Technical Parameter List of  ST/S800 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

(Execution Standard: MT668-2008)

Model

ST/S630

ST/S800

ST/S1000

ST/S1250

ST/S1600

ST/S2000

ST/S2500

ST/S2800

ST/S3150

ST/S3150

Max. Diameter of Steel Cord (mm)

3.0

3.5

4.0

4.5

5.0

6.0

7.2

7.5

8.1

8.6

Top Rubber Cover Thickness (mm)

5.0

5.0

6.0

6.0

6.0

8.0

8.0

8.0

8.0

8.0

Bottom Rubber Cover Thickness (mm)

5.0

5.0

6.0

6.0

6.0

8.0

8.0

8.0

8.0

8.0

Belt Width (mm)

No. Of Steel Cord

800

75

75

63

63

63

63

50

50

50

50

1000

95

95

79

79

79

79

64

64

64

64

1200

113

113

94

94

94

94

76

76

76

77

1400

133

133

111

111

111

111

89

89

89

90

1600

151

151

126

126

126

126

101

101

101

10-4

1800

-

171

143

143

143

143

114

114

114

114

2000

-

-

159

159

159

159

128

128

128

128

2200

-

-

-

-

-

176

141

141

141

141
